Specifications Uniview IPC3632LB-ADZK-H

Features	Description
Product Type	2MP HD IR Motorized Varifocal Eyeball Network Camera
Image Sensor	1/2.8″ Progressive Scan CMOS
Maximum Resolution	1920 × 1080
Frame Rate	Up to 30 fps @ 1920 × 1080
Lens	2.8 ~ 12 mm AF Motorized Varifocal Lens
Aperture	F1.6 Fixed Iris
Minimum Illumination	0.003 Lux (F1.6, AGC ON), 0 Lux with IR
Field of View	H: 103.6° ~ 33.4° / V: 54.8° ~ 18.7° / D: 107.9° ~ 37.8°
WDR	120 dB True WDR
IR Range	Up to 40 m
Video Compression	Ultra 265 / H.265 / H.264 / MJPEG
Video Streams	Dual Streams
Image Enhancement	2D/3D DNR / BLC / HLC / Digital Defog / Smart IR
Smart Functions	Motion Detection / Ultra Motion Detection / Cross Line Detection / Intrusion Detection / Tampering Alarm / Audio Detection
Audio	Built-in Microphone
Storage	MicroSD up to 512GB / ANR / NAS
Network Interface	1 × RJ45 10/100M Base-TX Ethernet
ONVIF	Profile S / Profile G / Profile T
Power Supply	DC 12V ±25% / PoE IEEE 802.3af
Power Consumption	Max. 7.5 W
Ingress Protection	IP67
Surge Protection	6 KV
Adjustment	Pan: 0° ~ 360° / Tilt: 0° ~ 75° / Rotate: 0° ~ 360°
Operating Temperature	-30°C ~ 60°C
Dimensions	Φ129 × 110 mm
Weight	0.66 kg

CAMERA & LENS
Image Sensor	1/2.8″ 2MP Progressive Scan CMOS
Resolution	1920 × 1080
Lens	2.8 ~ 12 mm AF Automatic Focusing Motorized Zoom Lens
Aperture	F1.6 Fixed Iris
Field of View	H: 103.6° ~ 33.4° / V: 54.8° ~ 18.7° / D: 107.9° ~ 37.8°
Minimum Illumination	0.003 Lux (F1.6, AGC ON), 0 Lux with IR
WDR	120 dB True WDR

VIDEO & IMAGE
Video Compression	Ultra 265 / H.265 / H.264 / MJPEG
Main Stream	1920 × 1080 @ Max. 30 fps
Sub Stream	720P / D1 / 640 × 360 @ Max. 30 fps
Video Bit Rate	128 Kbps ~ 6144 Kbps
DNR	2D/3D DNR
ROI	Up to 8 Areas
Privacy Mask	Up to 4 Areas
Smart IR	Supported
Corridor Mode	9:16 Supported

INTELLIGENT FEATURES
Motion Detection	Supported
Ultra Motion Detection	Supported
Cross Line Detection	Based on Human Body Detection
Intrusion Detection	Based on Human Body Detection
Tampering Alarm	Supported
Audio Detection	Supported

AUDIO & STORAGE
Microphone	Built-in Microphone
Two-Way Audio	Not Supported
MicroSD	Up to 512GB
Network Storage	ANR / NAS (NFS)

NETWORK
Network Interface	1 × RJ45 10/100M Base-TX
ONVIF	Profile S / Profile G / Profile T
Protocols	IPv4 / IPv6 / TCP / UDP / DHCP / RTP / RTSP / RTCP / DNS / DDNS / NTP / FTP / UPnP / HTTP / HTTPS / SMTP / SSL/TLS / QoS / SNMP
Security	Password Protection / HTTPS Encryption / RTSP Authentication / HTTP Authentication / TLS 1.2

POWER & PROTECTION
Power Supply	DC 12V ±25% / PoE IEEE 802.3af
Power Consumption	Max. 7.5 W
Ingress Protection	IP67
Surge Protection	6 KV
Operating Temperature	-30°C ~ 60°C

Note: The Uniview IPC3632LB-ADZK-H is a 2MP HD IR Motorized Varifocal Eyeball Network Camera featuring a 1/2.8″ CMOS sensor, 2.8–12mm AF motorized varifocal lens, 120dB True WDR, Smart IR up to 40m, Ultra 265 video compression, built-in microphone, MicroSD storage up to 512GB, PoE support and IP67 protection. It also supports human-based cross line and intrusion detection.
