General Specifications
| Antenna Patterns, per band | 4000+ |
| Antenna Gain | Up to 3 dBi |
| BeamFlex | Yes |
| ChannelFly | Yes |
| Concurrent Users | 1024 |
| Controller Support | SmartZone | Standalone | Unleashed | ZoneDirector |
| Ethernet Ports | 1x1GbE | 1×2.5GbE |
| IoT Ready | Yes |
| PD-MRC | Yes |
| PHY Rate at 2.4 GHz, maximum | 1148 Mb/s |
| PHY Rate at 5 GHz, maximum | 2400 Mb/s |
| Radio Chains and Streams | 4×4:4 |
| Rx Sensitivity at 2.4 GHz | -102 dBm |
| Rx Sensitivity at 5 GHz | -102 dBm |
| SmartMesh | Yes |
| USB | USB 2.0 |
| Venue Type | Education | Hospitality | Office/Retail | Public Venue |
| Venue Sub-Type | Cafeteria/Multipurpose Room | Library | Lobby/Common Spaces | Meeting Rooms | Venue VIP Rooms |
| Wi-Fi Interface Standard | IEEE 802.11a/b/g/n/ac/ax |
| Wi-Fi Interface Standard at 2.4 GHz | 802.11ax |
| Wi-Fi Interface Standard at 5 GHz | 802.11ax |
Environmental Specifications
| Operating Temperature | 0 °C to +50 °C (+32 °F to +122 °F) |
