Specifications TP-Link Tapo C530WS
| Features |
Description |
| Product Type |
Outdoor Pan/Tilt Security Wi-Fi Camera |
| Resolution |
3K 5MP (2880 × 1620 pixels) |
| Image Sensor |
1/2.7″ Progressive Scan CMOS Starlight Sensor |
| Lens |
4.0mm, F1.6 Aperture |
| Pan/Tilt |
360° Pan Coverage / 135.5° Tilt Coverage |
| Night Vision |
Starlight Color Night Vision and 850nm IR Night Vision up to 29.9m |
| Wireless |
2.4GHz Wi-Fi 6 (IEEE 802.11b/g/n/ax) |
| Ethernet |
1 × 10/100Mbps RJ45 Port |
| Storage |
MicroSD Card up to 512GB and Tapo Care Cloud Storage |
| AI Detection |
Person, Pet, Vehicle, Motion, Line-Crossing and Tamper Detection |
| Audio |
Two-Way Audio with Noise Cancellation and 93dB Siren |
| Weather Resistance |
IP66 |
| CAMERA |
| Image Sensor |
1/2.7″ Progressive Scan CMOS Starlight Sensor |
| Lens |
4.0mm, F1.6 Aperture |
| Maximum Resolution |
3K 5MP (2880 × 1620 pixels) |
| Field of View |
105.3° Diagonal / 88° Horizontal / 46° Vertical |
| Pan Range |
340° Mechanical Range / 360° Pan Coverage |
| Tilt Range |
90° Mechanical Range / 135.5° Tilt Coverage |
| Frame Rate |
15/20/25/30 fps (Default 15 fps) |
| Digital Zoom |
12× |
| Video Compression |
H.264 |
| Image Enhancement |
3DNR and WDR |
| Night Vision |
850nm IR LED up to 29.9m and Starlight Color Night Vision |
| Spotlights |
2 × Built-in Spotlights |
| VIDEO & AUDIO |
| Live View |
Supported |
| Audio Input |
Built-in Microphone |
| Audio Output |
Built-in Speaker |
| Two-Way Audio |
Supported with Noise Cancellation |
| Siren |
93dB at 10cm |
| Privacy Mode |
Physical Privacy Mode |
| DETECTION & NOTIFICATIONS |
| Motion Detection |
Supported |
| Person Detection |
Supported |
| Pet Detection |
Supported |
| Vehicle Detection |
Supported |
| Line-Crossing Detection |
Supported |
| Tamper Detection |
Supported |
| Activity Zones |
Supported |
| AI Processing |
On-Device Machine Learning |
| STORAGE |
| Local Storage |
MicroSD Card up to 512GB |
| Cloud Storage |
Tapo Care Cloud Storage Service (Subscription Required) |
| NETWORK |
| Wireless Connectivity |
2.4GHz Wi-Fi |
| Wi-Fi Standard |
IEEE 802.11b/g/n/ax (Wi-Fi 6) |
| Ethernet |
1 × 10/100Mbps RJ45 Port |
| RTSP |
Supported |
| ONVIF |
Supported |
| Security |
128-bit AES Encryption with SSL/TLS and WPA/WPA2-PSK |
| POWER |
| Power Source |
9V DC Power Adapter |
| Input Voltage |
100–240V, 50/60Hz |
| Output Voltage |
9V / 0.85A DC |
| GENERAL |
| Weather Resistance |
IP66 Weatherproof |
| Smart Integration |
Google Assistant and Amazon Alexa |
| Mounting |
Ceiling-Mounted, Wall-Mounted or Pole-Mounted |
| Operating Temperature |
-30°C to 60°C |
| Storage Temperature |
-40°C to 60°C |
| Operating Humidity |
10% to 90% RH, Non-Condensing |
| Dimensions |
123.8 × 123 × 90 mm |
| Certifications |
CE, FCC, RoHS and RCM |
Note: The TP-Link Tapo C530WS is a 5MP 3K Outdoor Pan/Tilt Security Wi-Fi Camera featuring a 1/2.7″ Starlight CMOS sensor, Starlight Color Night Vision, 360° pan coverage, 135.5° tilt coverage, AI person/pet/vehicle detection, two-way audio, local microSD storage up to 512GB and IP66 weather resistance. It supports both 2.4GHz Wi-Fi and 10/100Mbps Ethernet, as well as RTSP and ONVIF.
Important: The Tapo C530WS uses a 9V DC power adapter. Although it has an Ethernet port, TP-Link does not specify PoE support for this model. Ethernet is provided for network connectivity, while power is supplied separately.
