Specifications TP-Link LS106LP
| Features | Description |
|---|---|
| Device Type | 6-Port 10/100Mbps Desktop Switch with 3-Port PoE+ |
| Network Ports | 3 × 10/100Mbps PoE+ RJ45 Ports, 2 × 10/100Mbps RJ45 Ports, 1 × 10/100Mbps RJ45 Uplink |
| PoE Standard | IEEE 802.3af |
| PoE Ports | Ports 1–3 |
| PoE Power | Up to 15.4 W per PoE Port |
| PoE Budget | 40 W |
| Transmission Distance | Up to 250 m in Extend Mode |
| Isolation Mode | Separates PoE Ports from Each Other to Improve Network Security |
| PoE Auto Recovery | Automatically Detects and Reboots Unresponsive PoE Devices |
| Switching Capacity | 1.2 Gbps |
| Packet Forwarding Rate | 0.8928 Mpps |
| Application | IP Cameras, VoIP Phones, Access Points and Small Surveillance Networks |
| Interface | 3 × 10/100Mbps PoE+ RJ45, 3 × 10/100Mbps RJ45 |
|---|---|
| PoE Standard | IEEE 802.3af |
| PoE Ports | Ports 1–3 |
| PoE Power | Up to 15.4 W per Port |
| Total PoE Budget | 40 W |
| Network Speed | 10/100Mbps |
| Switching Capacity | 1.2 Gbps |
| Packet Forwarding Rate | 0.8928 Mpps |
| MAC Address Table | 2K |
| Jumbo Frame | 2 KB |
| Transmission Method | Store-and-Forward |
| Auto Negotiation | Supported |
| Auto MDI/MDIX | Supported |
| Extend Mode | Up to 250 m |
| Isolation Mode | Supported |
| PoE Auto Recovery | Supported |
| Flow Control | IEEE 802.3x Flow Control |
| Fan | Fanless |
| Power Supply | 48 VDC / 0.85 A External Power Adapter |
| Maximum Power Consumption | 48.8 W |
| SMART FEATURES | |
|---|---|
| 3-Port PoE+ | Provides Three 10/100Mbps PoE Ports Supporting IEEE 802.3af Devices with Up to 15.4 W per Port |
| 40W PoE Budget | Provides Up to 40 W Total PoE Power for IP Cameras, Access Points and VoIP Devices |
| 250m Extend Mode | Extends PoE Data and Power Transmission Distance up to 250 m for Long-Distance Surveillance Deployments |
| PoE Auto Recovery | Automatically Detects Unresponsive PoE Devices and Reboots Them to Maintain Stable Operation |
| Isolation Mode | Separates PoE Port Traffic to Improve Network Security and Reduce Network Interference |
| Fanless Design | Silent Fanless Construction Provides Reliable Operation with Low Noise and Low Maintenance |
| GENERAL | |
|---|---|
| Switch Type | Unmanaged PoE+ Desktop Switch |
| PoE Ports | 3 × 10/100Mbps PoE+ |
| Uplink Ports | 3 × 10/100Mbps RJ45 |
| PoE Budget | 40 W |
| Installation Method | Desktop / Wall Mount |
| Extend Distance | Up to 250 m |
| MAC Address Table | 2K |
| Operating Temperature | 0°C to 40°C |
| Storage Temperature | -40°C to 70°C |
| Operating Humidity | 10% to 90%, Non-Condensing |
| Storage Humidity | 5% to 90%, Non-Condensing |
| Dimensions | 99.8 × 98 × 25 mm |
| Certification | CE, FCC and RoHS |
| Warranty | 3 Years |
Note: The TP-Link LS106LP is a 6-port 10/100Mbps unmanaged desktop switch featuring 3 × PoE+ ports and 3 × non-PoE ports. It supports IEEE 802.3af PoE with up to 15.4 W per port and a total PoE budget of 40 W, making it suitable for small IP camera, access point and VoIP deployments.
Important: The TP-Link LS106LP supports Extend Mode for up to 250 m PoE transmission, Isolation Mode for separating PoE port traffic and PoE Auto Recovery for automatically detecting and rebooting unresponsive PoE devices. Its fanless design provides quiet and maintenance-free operation for desktop and surveillance installations.
