Specifications Hikvision DS-2CD1047G2H-LIU
| Features | Description |
|---|---|
| Product Type | 4 MP ColorVu Smart Hybrid Light Fixed Bullet Network Camera |
| Camera Type | Bullet IP Camera |
| Image Sensor | 1/3″ Progressive Scan CMOS |
| Maximum Resolution | 2560 × 1440 |
| Lens | Fixed Focal Lens, 2.8 mm / 4 mm Optional |
| Minimum Illumination | Color: 0.001 Lux @ (F1.0, AGC ON), 0 Lux with Light |
| Supplement Light | IR + White Light, Up to 30 m |
| WDR | 120 dB |
| Video Compression | H.265+ / H.265 / H.264+ / H.264 |
| Smart Detection | Human and Vehicle Detection |
| Audio | Built-in Microphone |
| Network Interface | 1 × RJ45 10/100 Mbps Ethernet |
| PoE | IEEE 802.3af, Class 3 |
| CAMERA | |
|---|---|
| Image Sensor | 1/3″ Progressive Scan CMOS |
| Maximum Resolution | 2560 × 1440 |
| Minimum Illumination | Color: 0.001 Lux @ (F1.0, AGC ON), 0 Lux with Light |
| Shutter Time | 1/3 s to 1/100,000 s |
| Day/Night | IR Cut Filter |
| Angle Adjustment | Pan: 0° to 360°, Tilt: 0° to 90°, Rotate: 0° to 360° |
| WDR | 120 dB |
| Image Enhancement | BLC, HLC, 3D DNR |
| SNR | ≥52 dB |
| LENS | |
|---|---|
| Lens Type | Fixed Focal Lens |
| Focal Length | 2.8 mm / 4 mm Optional |
| Lens Mount | M12 |
| Iris Type | Fixed |
| Aperture | F1.0 |
| FOV – 2.8 mm | Horizontal: 115°, Vertical: 60°, Diagonal: 143° |
| FOV – 4 mm | Horizontal: 94°, Vertical: 50°, Diagonal: 110° |
| DORI | |
|---|---|
| 2.8 mm | Detect: 64 m, Observe: 25 m, Recognize: 12 m, Identify: 6 m |
| 4 mm | Detect: 77 m, Observe: 30 m, Recognize: 15 m, Identify: 7 m |
| ILLUMINATOR | |
|---|---|
| Supplement Light Type | IR + White Light |
| Supplement Light Range | Up to 30 m |
| Smart Supplement Light | Supported |
| IR Wavelength | 850 nm |
| ColorVu | Supported |
| VIDEO | |
|---|---|
| Main Stream | 50 Hz: 20 fps (2560 × 1440), 25 fps (1920 × 1080, 1280 × 720) |
| 60 Hz | 20 fps (2560 × 1440), 24 fps (1920 × 1080, 1280 × 720) |
| Sub-Stream | 25 fps (50 Hz) / 24 fps (60 Hz) at 1280 × 720, 640 × 480, 640 × 360 |
| Video Compression | H.265+ / H.265 / H.264+ / H.264 |
| Sub-Stream Compression | H.265 / H.264 / MJPEG |
| Video Bit Rate | 32 Kbps to 16 Mbps |
| H.264 Profile | Baseline / Main / High Profile |
| H.265 Profile | Main Profile |
| Bit Rate Control | CBR / VBR |
| SVC | H.264 and H.265 Encoding |
| ROI | 1 Fixed Region for Main Stream |
| AUDIO | |
|---|---|
| Audio | Built-in Microphone, Mono Sound |
| Audio Compression | G.711 / G.722.1 / G.726 / MP2L2 / PCM / AAC-LC |
| Audio Bit Rate | 16 to 160 Kbps depending on codec |
| Audio Sampling Rate | 8 kHz / 16 kHz |
| Environment Noise Filtering | Supported |
| SMART FEATURES | |
|---|---|
| Motion Detection | Supported |
| Human Detection | Supported |
| Vehicle Detection | Supported |
| Video Tampering Alarm | Supported |
| Exception Detection | Supported |
| NETWORK | |
|---|---|
| Network Interface | 1 × RJ45 10/100 Mbps Self-Adaptive Ethernet Port |
| Protocols | IPv4, IPv6, TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, RTCP, NTP, IGMP, UDP, QoS, FTP, SMTP, UPnP |
| Simultaneous Live View | Up to 6 Channels |
| API | ONVIF Profile S / T, ISAPI, SDK |
| Maximum Users | Up to 32 Users |
| User Levels | Administrator / Operator / User |
| Client Software | iVMS-4200 / Hik-Connect |
| STORAGE | |
|---|---|
| MicroSD Card | Not Supported on DS-2CD1047G2H-LIU |
| Network Storage | NVR / NAS |
| Recording Method | Network Recording |
| POE & POWER | |
|---|---|
| PoE Standard | IEEE 802.3af, Class 3 |
| PoE Power Consumption | Max. 7.5W |
| DC Power | 12 VDC ±25%, 0.5A |
| Maximum Power Consumption | Max. 6W via DC |
| PROTECTION & GENERAL | |
|---|---|
| Protection | IP67 |
| Housing | Metal Front Cover / Plastic Body / Plastic Bracket |
| Dimensions | 69.8 × 67.9 × 172.9 mm |
| Weight | Approx. 550g |
| Operating Temperature | -30°C to 60°C |
| Operating Humidity | Up to 95% RH, Non-Condensing |
Note: The Hikvision DS-2CD1047G2H-LIU is a 4 MP ColorVu Smart Hybrid Light Fixed Bullet Network Camera featuring a 1/3″ Progressive Scan CMOS sensor and 2560 × 1440 resolution. It supports 2.8 mm or 4 mm fixed lenses, 120 dB WDR, H.265+ compression, Human and Vehicle Detection, built-in microphone and Smart Hybrid Light with IR and white light up to 30 m. The camera supports IEEE 802.3af PoE and is IP67 water and dust resistant.
Important: The Hikvision DS-2CD1047G2H-LIU is a 4 MP ColorVu Fixed Bullet IP Camera featuring Smart Hybrid Light, 120 dB WDR and Human & Vehicle Detection. It provides 2560 × 1440 resolution, supports 2.8 mm / 4 mm lenses and provides supplemental lighting up to 30 m. The camera has a built-in microphone, supports IEEE 802.3af PoE and has an IP67 protection rating. The LIU model does not include a MicroSD card slot; MicroSD storage up to 512 GB is available on the LIUF variant.
