Specifications Hikvision DS-2CD2955G0-ISU
| Features |
Description |
| Product Type |
5MP Fixed Fisheye Network Camera |
| Camera Type |
Fisheye Network Camera |
| Image Sensor |
1/2.7″ Progressive Scan CMOS |
| Maximum Resolution |
5MP (2560 × 1920) |
| Lens |
1.05 mm Fixed Fisheye Lens |
| Field of View |
180° Horizontal / 180° Vertical / 180° Diagonal |
| WDR |
120 dB True WDR |
| IR Range |
Up to 8 m |
| Video Compression |
H.265+ / H.265 / H.264+ / H.264 |
| Storage |
MicroSD up to 256GB |
| PoE |
IEEE 802.3af, Class 3 |
| CAMERA |
| Image Sensor |
1/2.7″ Progressive Scan CMOS |
| Maximum Resolution |
2560 × 1920 |
| Minimum Illumination |
Color: 0.017 Lux @ F2.25, AGC ON; B/W: 0 Lux with IR |
| Shutter Speed |
1/3 s to 1/100,000 s |
| Day/Night |
IR Cut Filter |
| Wide Dynamic Range |
120 dB True WDR |
| Image Enhancement |
BLC / 3D DNR |
| LENS |
| Lens Type |
Fixed Focal Fisheye Lens |
| Focal Length |
1.05 mm |
| Field of View |
Horizontal: 180°
Vertical: 180°
Diagonal: 180° |
| Lens Mount |
M12 |
| Focus |
Fixed |
| Iris Type |
Fixed |
| Aperture |
F2.25 |
| Depth of Field |
0.1 m to ∞ |
| DORI |
| Detect |
21 m |
| Observe |
8 m |
| Recognize |
4 m |
| Identify |
2 m |
| FISHEYE DISPLAY |
| Mounting |
Wall / Table / Ceiling Mounting |
| Fisheye View |
180° Panoramic View |
| Display Modes |
Fisheye / Panoramic / PTZ Display Modes |
| ILLUMINATOR |
| Supplement Light Type |
IR |
| IR Range |
Up to 8 m |
| IR Wavelength |
850 nm |
| Smart Supplement Light |
Supported |
| VIDEO |
| Main Stream |
50 Hz: 25 fps up to 2560 × 1920
60 Hz: 30 fps up to 2560 × 1920 |
| Sub-Stream |
50 Hz: 25 fps / 60 Hz: 30 fps up to 640 × 480 |
| Video Compression |
H.265+ / H.265 / H.264+ / H.264 |
| Sub-Stream Compression |
H.265 / H.264 / MJPEG |
| Video Bit Rate |
32 Kbps to 16 Mbps |
| H.264 Profile |
Baseline / Main / High Profile |
| H.265 Profile |
Main Profile |
| ROI |
1 Fixed Region for Main Stream |
| IMAGE FEATURES |
| WDR |
120 dB True WDR |
| Backlight Compensation |
Supported |
| 3D DNR |
Supported |
| Privacy Mask |
Supported |
| Image Adjustment |
Brightness / Contrast / Saturation / Sharpness |
| SMART FEATURES |
| Motion Detection |
Supported |
| Video Tampering Detection |
Supported |
| Exception Detection |
Supported |
| Line Crossing Detection |
Supported |
| Intrusion Detection |
Supported |
| Smart Event |
Line Crossing / Intrusion Detection |
| AUDIO |
| Built-in Microphone |
Supported |
| Audio Type |
Mono Sound |
| Audio Input |
1 × Line In |
| Audio Output |
1 × Line Out |
| Audio Compression |
G.711 μ-law / G.711 A-law / G.722.1 / G.726 / MP2L2 / PCM / AAC-LC |
| Environment Noise Filtering |
Supported |
| NETWORK |
| Network Interface |
1 × RJ45 10/100M Self-Adaptive Ethernet Port |
| Protocols |
TCP/IP / ICMP / HTTP / HTTPS / FTP / DHCP / DNS / DDNS / RTP / RTSP / RTCP / PPPoE / NTP / UPnP / SMTP / SNMP / IGMP / 802.1X / QoS / IPv6 / Bonjour / IPv4 / UDP / SSL/TLS |
| Integration |
ONVIF Profile S / Profile G / Profile T |
| API |
ISAPI |
| Simultaneous Live View |
Up to 6 Channels |
| Client Software |
iVMS-4200 / Hik-Connect |
| STORAGE |
| MicroSD Card |
Up to 256GB |
| Storage Type |
MicroSD / MicroSDHC / MicroSDXC |
| Network Storage |
NAS / NFS / SMB / CIFS |
| ANR |
Supported |
| INTERFACE |
| Ethernet |
1 × RJ45 10/100M |
| Alarm Input |
1 |
| Alarm Output |
1 |
| Audio Input |
1 × Line In |
| Audio Output |
1 × Line Out |
| Reset Button |
Supported |
| Power Output |
12 VDC, Max. 100 mA |
| POE & POWER |
| PoE Standard |
IEEE 802.3af, Class 3 |
| Power Supply |
12 VDC ±25% |
| Maximum Power Consumption |
6 W (12 VDC) / 7.5 W (PoE) |
| Power Interface |
Ø5.5 mm Coaxial Power Plug |
| PROTECTION & GENERAL |
| Housing Material |
ADC12 |
| Anti-Corrosion Protection |
No Specific Protection |
| Operating Temperature |
-10°C to 50°C |
| Operating Humidity |
≤95% RH, Non-Condensing |
| Dimensions |
Ø119.9 × 41.2 mm |
| Net Weight |
Approx. 320 g |
Note: The Hikvision DS-2CD2955G0-ISU is a 5MP Fixed Fisheye Network Camera featuring a 1/2.7″ Progressive Scan CMOS sensor, 2560 × 1920 resolution and a 1.05 mm fisheye lens providing 180° horizontal, vertical and diagonal field of view. It supports 120 dB True WDR, H.265+ compression, IR up to 8 m, built-in microphone, audio/alarm interfaces, MicroSD storage up to 256GB and IEEE 802.3af PoE.
Important: The Hikvision DS-2CD2955G0-ISU is a 5MP Fixed Fisheye Network Camera featuring a 1.05 mm fisheye lens with 180° panoramic viewing. It provides 120 dB True WDR, H.265+ compression, up to 8 m IR, line crossing and intrusion detection. The camera also supports built-in microphone, audio/alarm I/O, MicroSD up to 256GB and IEEE 802.3af PoE.
