คุณสมบัติ Hikvision HF-VTR344
| Features | Description |
|---|---|
| Camera Type | 4MP Thermal + AI Fire Detection Fusion Bullet Network Camera |
| Detection Technology | Thermal Imaging + Visible Light Camera + Infrared Flame Detection |
| Visible Sensor | 1/2.7″ Progressive Scan CMOS |
| Maximum Resolution | 2560 × 1440 @ 25/30fps |
| Lens | 3 mm Fixed Lens |
| Fire Detection | AI Flame Detection, Smoke Detection, High Temperature Detection |
| Detection Range | Flame Detection up to 50 m |
| Temperature Measurement | Thermal Temperature Detection with Abnormal Temperature Alarm |
| Audio | Built-in Speaker & Microphone, Two-Way Audio |
| Network | RJ45 10/100 Mbps Ethernet with PoE Support |
| Protection | IP66 Weatherproof |
| Power Supply | DC 9–36V / PoE (IEEE 802.3at) |
| Camera Type | 3-in-1 Fusion Fire Detection Camera |
|---|---|
| Thermal Sensor | Tri-Band Infrared Flame Detection Sensor |
| Visible Sensor | 1/2.7″ Progressive Scan CMOS |
| Resolution | 2560 × 1440 (4MP) |
| Lens | 3 mm Fixed Lens |
| Viewing Angle | Approx. 100° Wide Angle |
| PERFORMANCE | |
|---|---|
| AI Detection | Flame Detection, Smoke Detection, Fire Point Location, Temperature Abnormality Detection |
| Fire Detection Range | Up to 50 m |
| Temperature Alarm | High Temperature & Temperature Rise Rate Detection |
| Image Enhancement | 120 dB WDR, 3D DNR, BLC |
| Alarm Function | Voice Alarm, Indicator Light, Remote Silence |
| NETWORK | |
|---|---|
| Ethernet | 1 × RJ45 10/100 Mbps Adaptive Ethernet |
| Protocols | TCP/IP, HTTP, HTTPS, RTSP, FTP, DHCP, DNS, NTP |
| Storage | MicroSD / SDHC / SDXC Card up to 128GB |
| Compatibility | ONVIF, ISAPI, Hik-Connect |
| INTERFACE | |
|---|---|
| Alarm Interface | 2 Alarm Inputs / 2 Alarm Outputs |
| Audio Interface | 1 Audio Input / 1 Audio Output |
| Communication | RS-485 Interface |
| Analog Output | 4–20mA Current Output Interface |
| GENERAL | |
|---|---|
| Power Supply | DC 9–36V / PoE IEEE 802.3at |
| Power Consumption | Max. 24 W |
| Operating Temperature | -20°C to 60°C |
| Weather Protection | IP66 |
| Dimensions | 212.5 × 130 × 84.8 mm |
| Weight | Approx. 1.4 kg |
Note: Product specifications and software features are subject to change without prior notice. Please refer to the latest official information before installation.
Important: The Hikvision HF-VTR344 is a 3-in-1 fusion fire detection camera combining thermal imaging, visible video verification, and infrared flame detection. It supports flame detection up to 50 meters, smoke/fire alarm, temperature abnormality detection, voice alarm, PoE power supply, and integration with Hikvision security platforms.
