Specifications LINK UFC3324A
| Features | Description |
|---|---|
| Device Type | Outdoor/Indoor Armored Fiber Optic Cable |
| Fiber Type | OM4 Multimode 50/125 μm |
| Core Count | 24 Core (Multi-Tube) |
| Cable Construction | Multi-Tube, Corrugated Steel Tape Armored |
| Water Blocking | Gel Filled Loose Tubes with Water Blocking Yarn |
| Strength Member | Central FRP Strength Member with Water Blocking Yarn |
| Armor Protection | Corrugated Steel Tape for Rodent and Mechanical Protection |
| Outer Jacket | UV-Resistant FR-LSZH Black PE |
| Cable Length | Available by Meter (M) |
| Application | Direct Burial, Duct, Aerial, Campus Backbone, Building Backbone, FTTx, CATV, CCTV and Enterprise Networks |
| Cable Standard | ANSI/TIA-568.3-D, ISO/IEC 11801:2017 |
|---|---|
| Fiber Standard | ITU-T G.651 OM4 Multimode |
| Core Size | 50/125 μm |
| Number of Fibers | 24 Core |
| Fiber Construction | Multi-Tube Gel Filled Design |
| Strength Member | Central FRP with Water Blocking Yarn |
| Armor | Corrugated Steel Tape |
| Outer Jacket | UV-Resistant FR-LSZH Black PE |
| Cable Weight | Approximately 250 ± 10 kg/km |
| Packaging | Available by Meter (M) |
| SMART FEATURES | |
|---|---|
| Multi-Tube Design | Supports High Fiber Count with Improved Fiber Organization and Easier Fiber Splicing |
| Steel Armored Protection | Corrugated Steel Tape Protects Against Rodents, Impact and Mechanical Damage |
| Water Blocking Design | Gel-Filled Loose Tubes and Water Blocking Yarn Prevent Moisture Penetration |
| LSZH Flame Retardant Jacket | Low Smoke Zero Halogen Jacket Improves Fire Safety for Indoor Installations |
| High-Speed Transmission | Supports 10G, 40G and 100G Ethernet, Fiber Channel, FTTx, CATV, CCTV and Backbone Networks |
| GENERAL | |
|---|---|
| Cable Type | Outdoor/Indoor Armored Multi-Tube Fiber Optic Cable |
| Installation Method | Direct Burial, Duct and Aerial Installation |
| Minimum Bend Radius | 15 × Cable Diameter (Installation), 10 × Cable Diameter (Operation) |
| Installation / Operating Temperature | -40°C to +70°C |
| Storage Temperature | -40°C to +75°C |
| Standards Compliance | ANSI/TIA-568.3-D, ANSI/TIA-568.3-E, ANSI/ICEA 696, ANSI/ICEA 596, ANSI/ICEA 640, ISO/IEC 11801:2017, IEC 60793, IEC 60794-1-2, IEC 60332-1-2, IEC 60332-3, IEC 61034-2, IEC 60754-2, Telcordia GR-20-CORE, GR-409-CORE, ITU-T G.651, EN 50173-1, TIS 2165, RoHS |
| Warranty | 30 Years |
Note: The LINK UFC3324A is a 24-core OM4 50/125 μm multimode armored fiber optic cable featuring a multi-tube construction for high-density backbone applications. It incorporates corrugated steel tape armor, gel-filled loose tubes, water-blocking yarn, a central FRP strength member, and a UV-resistant FR-LSZH jacket, making it suitable for direct burial, duct and aerial installations in enterprise, campus and industrial networks.
Important: The LINK UFC3324A supports high-speed Ethernet applications including Gigabit Ethernet, 10G, 40G and 100G Ethernet, Fiber Channel, FTTx, CATV and CCTV backbone networks. Its OM4 multimode fiber provides enhanced bandwidth performance for enterprise and data center network applications, while the armored multi-tube construction offers excellent protection against moisture, rodent damage and harsh outdoor environments.
