Specifications LINK UFC4324
| Features | Description |
|---|---|
| Device Type | Outdoor/Indoor All-Dielectric Fiber Optic Cable |
| Fiber Type | OM3 XG Multimode 50/125 μm |
| Core Count | 24 Core |
| Cable Construction | Single Loose Tube, All-Dielectric |
| Water Blocking | Waterproof Gel Filled Tube with Water Blocking E-Glass Yarn |
| Strength Member | Water Blocking E-Glass Yarn (Non-Metallic) |
| Outer Jacket | UV-Resistant FR-LSZH (Low Smoke Zero Halogen) |
| Jacket Color | Black |
| Cable Length | Sold by Meter (M) |
| Application | Campus Backbone, Building Backbone, Indoor/Outdoor Duct, Lash Aerial, Data Center, FTTx, CATV, CCTV and Enterprise Networks |
| Cable Standard | ANSI/TIA-568.3-D, ISO/IEC 11801:2017 |
|---|---|
| Fiber Standard | ITU-T G.651.1 OM3 Multimode |
| Core Size | 50/125 μm |
| Number of Fibers | 24 Core |
| Fiber Construction | Single Loose Tube with Waterproof Gel Filling |
| Strength Member | Water Blocking E-Glass Yarn |
| Rip Cord | Included |
| Outer Jacket | UV-Resistant FR-LSZH |
| Cable Diameter | Approximately 8.5 ± 0.5 mm |
| Cable Weight | Approximately 60 ± 5 kg/km |
| SMART FEATURES | |
|---|---|
| All-Dielectric Design | Non-Metallic Construction Eliminates Electrical Conductivity and Grounding Requirements |
| OM3 XG Multimode Fiber | Optimized for High-Speed VCSEL Laser Transmission in Enterprise Networks and Data Centers |
| Water Blocking Protection | Gel-Filled Loose Tube and E-Glass Yarn Prevent Moisture Penetration and Improve Outdoor Reliability |
| LSZH Flame Retardant Jacket | Provides Low Smoke and Zero Halogen Performance for Safer Indoor Installations |
| High-Speed Optical Transmission | Supports 10G, 40G and 100G Ethernet, Fiber Channel, FTTx, CATV and CCTV Applications |
| GENERAL | |
|---|---|
| Cable Type | Outdoor/Indoor All-Dielectric Single Loose Tube Fiber Optic Cable |
| Maximum Tensile Load | 1,800 N (Installation) / 900 N (Operation) |
| Maximum Crush Resistance | 1,500 N / 10 cm |
| Minimum Bend Radius | 15 × Cable Diameter (Installation), 10 × Cable Diameter (Operation) |
| Installation / Operating Temperature | -40°C to +70°C |
| Storage Temperature | -40°C to +75°C |
| Standards Compliance | ANSI/TIA-568.3-D, ANSI/TIA-568-C.3, ISO/IEC 11801:2017, IEC 60793, IEC 60794-1-2, IEC 60332-1-2, IEC 61034-2, IEC 60754-2, Telcordia GR-20-CORE, ITU-T G.651.1, TIS 2165, RoHS |
| Packaging | Available by Meter (M) |
| Warranty | 30 Years |
Note: The LINK UFC4324 is a 24-core OM3 XG 50/125 μm multimode fiber optic cable designed for indoor and outdoor installations. It features an all-dielectric construction, gel-filled single loose tube, water-blocking E-glass yarn, and a UV-resistant FR-LSZH jacket to ensure reliable high-speed optical transmission while providing excellent protection against moisture, UV exposure, and harsh environments.
Important: The LINK UFC4324 is optimized for VCSEL laser transmission and supports IEEE 802.3 Gigabit Ethernet, 10 Gigabit Ethernet, 40G and 100G Ethernet, Fiber Channel, FTTx, CATV, CCTV, and campus backbone applications. Its all-dielectric design eliminates grounding requirements and provides complete immunity to electromagnetic interference, making it ideal for duct and aerial backbone installations as well as high-density enterprise and data center networks.
