Specifications LINK UFC4324A
| Features | Description |
|---|---|
| Device Type | Outdoor/Indoor Armored Fiber Optic Cable |
| Fiber Type | OM3 Multimode 50/125 μm |
| Core Count | 24 Core (Multi-Tube) |
| Cable Construction | Multi-Tube, Corrugated Steel Tape Armored |
| Water Blocking | Gel Filled Loose Tubes with Water Blocking Yarn |
| Strength Member | Central FRP Strength Member with Water Blocking Yarn |
| Armor Protection | Corrugated Steel Tape for Rodent and Mechanical Protection |
| Outer Jacket | UV-Resistant FR-LSZH Black PE |
| Cable Length | Available by Meter (M) |
| Application | Direct Burial, Duct, Aerial, Campus Backbone, Building Backbone, FTTx, CATV, CCTV and Enterprise Networks |
| Cable Standard | ANSI/TIA-568.3-D, ISO/IEC 11801:2017 |
|---|---|
| Fiber Standard | ITU-T G.651 OM3 Multimode |
| Core Size | 50/125 μm |
| Number of Fibers | 24 Core |
| Fiber Construction | Multi-Tube Gel Filled Design |
| Strength Member | Central FRP with Water Blocking Yarn |
| Armor | Corrugated Steel Tape |
| Outer Jacket | UV-Resistant FR-LSZH Black PE |
| Cable Weight | Approximately 242 ± 5 kg/km |
| Packaging | Available by Meter (M) |
| SMART FEATURES | |
|---|---|
| Multi-Tube Design | Supports High Fiber Count with Improved Fiber Organization and Easier Fiber Splicing |
| Steel Armored Protection | Corrugated Steel Tape Protects Against Rodents, Impact and Mechanical Damage |
| Water Blocking Design | Gel-Filled Loose Tubes and Water Blocking Yarn Prevent Moisture Penetration |
| LSZH Flame Retardant Jacket | Low Smoke Zero Halogen Jacket Improves Fire Safety for Indoor Installations |
| High-Speed Transmission | Supports Gigabit Ethernet, 10G, 40G and 100G Ethernet, Fiber Channel, FTTx, CATV, CCTV and Backbone Networks |
| GENERAL | |
|---|---|
| Cable Type | Outdoor/Indoor Armored Multi-Tube Fiber Optic Cable |
| Installation Method | Direct Burial, Duct and Aerial Installation |
| Minimum Bend Radius | 15 × Cable Diameter (Installation), 10 × Cable Diameter (Operation) |
| Installation / Operating Temperature | -40°C to +70°C |
| Storage Temperature | -40°C to +75°C |
| Standards Compliance | ANSI/TIA-568.3-D, ANSI/TIA-568-C.3, ISO/IEC 11801:2017, ANSI/ICEA S-87-640, IEC 60793, IEC 60794-1-2, IEC 60332-1-2, IEC 60332-3, IEC 61034-2, IEC 60754-2, Telcordia GR-20-CORE, ITU-T G.651, RoHS |
| Warranty | 30 Years |
Note: The LINK UFC4324A is a 24-core OM3 50/125 μm multimode armored fiber optic cable featuring a multi-tube construction for high-density backbone applications. It incorporates corrugated steel tape armor, gel-filled loose tubes, water-blocking yarn, a central FRP strength member, and a UV-resistant FR-LSZH jacket, making it suitable for direct burial, duct and aerial installations in enterprise, campus and industrial networks.
Important: The LINK UFC4324A supports Gigabit Ethernet, 10G, 40G and 100G Ethernet, Fiber Channel, FTTx, CATV and CCTV backbone networks. Its OM3 multimode fiber provides high-bandwidth transmission for demanding network environments, while the steel armored multi-tube construction offers excellent resistance against moisture, rodent damage and harsh outdoor conditions.
