Specifications LINK UFC5206LSZH
| Features | Description |
|---|---|
| Device Type | Indoor Multi-Core LSZH Distribution Fiber Optic Cable |
| Fiber Type | OM2 50/125μm Multi-Mode Fiber |
| Core Count | 6 Core |
| Cable Construction | Tight Buffer / Distribution Structure with LSZH Sheath |
| Jacket Material | Dark Grey FR-LSZH (Flame Retardant Low Smoke Zero Halogen) |
| Installation | Indoor, Tray, Conduit, Data Center and Sub-Rack Distribution |
| Water Protection | Indoor Non-Waterproof Structure |
| Strength Member | Aramid Yarn (Kevlar) Reinforcement with Central Strength Member |
| Cable Length | 2,000 Meters per Drum (Available by Meter) |
| Application | Indoor Distribution, Backbone Cabling, Data Center, and Enterprise Networks |
| Fiber Standard | ITU-T G.651 OM2 Multi-Mode |
|---|---|
| Fiber Diameter | 50/125μm (0.9 mm Tight Buffer Fibers) |
| Flame Rating | FR-LSZH (Flame Retardant Low Smoke Zero Halogen) |
| Installation Type | Indoor Distribution and Trunk Cabling Installation |
| Standards | ANSI/TIA/EIA-568-D/E, ISO/IEC 11801:2017, IEC 60794-2, IEC 60332-1, IEC 61034-2, IEC 60754-2, ITU-T G.651, RoHS |
| Application | Gigabit Ethernet, 10G, 40G, 100G Ethernet, Optical Distribution, and Internal Backbone |
| SMART FEATURES | |
|---|---|
| Distribution Design | Compact Multi-Core Tight Buffer Structure Specially Designed for Indoor Backbone and Distribution Runs |
| Flame Retardant LSZH Jacket | FR-LSZH Sheath Minimizes Smoke and Halogen-Free Toxic Gas Emission During Fire |
| High Tensile Strength | Aramid Yarn Reinforcement and Central Strength Member Provide Excellent Pulling Strength |
| Easy Termination | Individual Tight Buffer Fibers Allow Direct Connectorization and Splice Preparation |
| High-Speed Network Support | Supports Gigabit Ethernet, 10G, 40G and 100G Network Applications |
| GENERAL | |
|---|---|
| Fiber Count | 6 Core |
| Cable Diameter | 5.5 ± 0.5mm |
| Cable Weight | Approx. 25 ± 5kg/km |
| Maximum Tensile Load | 400N (Installation), 200N (Operation) |
| Installation / Operating Temperature | -20°C to +70°C |
| Storage Temperature | -40°C to +75°C |
| Packing | 2,000m per Drum (Available by Meter) |
| Warranty | 30 Years |
Note: The LINK UFC5206LSZH is a 6-core OM2 50/125μm multimode distribution fiber optic cable featuring a dark grey flame-retardant low smoke zero halogen (LSZH) jacket, designed specifically for indoor multi-core distribution and backbone applications. It features tight buffer construction with flexible aramid yarn reinforcement. The cable complies with ANSI/TIA, ISO/IEC, IEC, and ITU-T standards, making it ideal for safe indoor data center routing, rack-to-rack links, and telecommunication network distribution.
Important: The LINK UFC5206LSZH is a 6-core OM2 (50/125μm) multimode distribution fiber optic cable featuring tight buffer construction, dark grey FR-LSZH flame-retardant jacket for safety, aramid yarn strength members, and direct termination capability. It supports Gigabit Ethernet, 10G, 40G, and 100G network applications and is ideal for indoor backbone routing, data center trunk wiring, and enterprise fiber optic infrastructure.
