Specifications LINK UFH9321
| Features | Description |
|---|---|
| Device Type | FTTR / FTTH Flat 1-Core Non-Metallic Fiber Optic Cable (Distribution Cable) |
| Brand / Series | LINK (Interlink) / Double-Q Series (Non-Metallic FTTH/FTTR Solution) |
| Fiber Type | Single-Mode Fiber (ITU-T G.657A2, Fully Compatible with G.652D) |
| Core Count | 1 Core (1C Structure) |
| Cable Construction | Flat Profile Distribution Cable with Non-Metallic Strength Members (FRP) |
| Jacket Material | Flame Retardant Low Smoke Zero Halogen (FR-LSZH) |
| Installation | Indoor and Outdoor Environmental Deployment (Non-Metallic, Dielectric Structure) |
| Packaging Length | Standard Box: 1,000 Meters / Box |
| Application | FTTx, FTTR (Fiber to the Room) Systems, CCTV Signal Transmission, Indoor Routing, and Enterprise Networks |
| Fiber Standard | ITU-T G.657A2 Single-Mode (Superior Bend Insensitivity) |
|---|---|
| Flame Rating | Meets IEC 60332-1, IEC 60754-1 & 2, and IEC 61034-2 Standards (LSZH Non-Flame Propagation) |
| Environmental Standards | RoHS Compliant |
| Electrical Safety | 100% Non-Metallic Structure — Completely Safe from Electrical Surges, Lightning Induction, and Power Interferences |
| SMART FEATURES | |
|---|---|
| Non-Metallic Safety Design | Contains zero metallic elements (utilizing fiberglass reinforced plastic strength members), eliminating electrical hazards and grounding risks |
| Low Smoke Zero Halogen | LSZH sheath ensures safety by minimizing smoke density and eliminating toxic halogen gases during fire incidents |
| Bend-Insensitive Performance | Built with G.657A2 optical fibers to accommodate tight indoor corner routing and complex architectural layouts without macro-bending signal loss |
| Lightweight & Flexible | Compact flat profile engineered for effortless pulling, stapling, and discreet surface-mount or duct routing inside residential and commercial spaces |
| GENERAL | |
|---|---|
| Core Diameter | Cladding 125$\mu$m Single-Mode Core Structure |
| Color | Black / White (Dependent on production batch) |
| Warranty | Standard Manufacturer Warranty (Up to 30 Years System Link Warranty when installed under certified guidelines) |
Note: The LINK UFH9321 is a 1-core single-mode flat non-metallic fiber optic distribution cable supplied in a 1,000-meter box. Utilizing bend-insensitive G.657A2 fiber and a safe LSZH jacket, its dielectric construction makes it completely immune to electrical interference, ideal for sensitive indoor data routing and CCTV connections.
Important: The LINK UFH9321 cable features a lightweight flat profile reinforced with non-metallic fiberglass elements. Because it contains no conductive metal components, it provides absolute protection against lightning strikes and power feedback, making it a preferred solution for professional indoor FTTR/FTTH distribution pathways.
