Specifications LINK US-5110SLZ-1
| Features | Description |
|---|---|
| Device Type | CAT 6 UTP RJ45-RJ45 Factory-Terminated Patch Cord (Slim Series) |
| Brand / Series | LINK (Interlink) / Slim LAN (UTP) High-Density System |
| Standard / Category | Category 6 (CAT 6 UTP) – Supports up to 10 Gbps Ethernet |
| Conductor Material | 28 AWG / Stranded Copper Wire with Ultra-Slim Outer Diameter Design |
| Jacket Material | Flame-Retardant Low Smoke Zero Halogen (FR-LSZH) |
| Connector Type | High-Performance Slim-Profile Modular RJ45 Plugs on Both Ends with Snagless Boot |
| Cable Length | 1.0 Meter |
| Color | White (or Selectable Slim Color Options) |
| Application | High-Density Switch-to-Server Patching, Data Center Racks, and Enterprise LAN Environments |
| Performance Standard | ANSI/TIA-568-C.2, ISO/IEC 11801, and EN 50173-1 Compliant |
|---|---|
| Power over Ethernet | Supports PoE and PoE+ (IEEE 802.3af / 802.3at) Applications |
| Environmental Standard | RoHS Compliant & Lead-Free Construction |
| Flame Rating | Meets IEC Standards for Non-Flame Propagation and Low Smoke Emission (LSZH) |
| SMART FEATURES | |
|---|---|
| Ultra-Slim High-Density Design | Significantly reduced outer diameter and connector profile optimize airflow in crowded server racks and simplify cable management |
| Low Smoke Zero Halogen (LSZH) | Jacket material designed for public safety; emits minimal smoke and zero toxic halogen gases during a fire hazard |
| Enhanced Flexibility | Thinner gauge construction provides exceptional bend radius and pliability for tight routing between patch panels and switches |
| Factory Terminated Reliability | Precision-molded at the factory to guarantee consistent high-frequency signal transfer and dependable 10 Gbps performance |
| GENERAL | |
|---|---|
| Packaging | Individual Factory Packaging |
| Warranty | Standard Manufacturer Warranty (Up to 30 Years System Link Warranty under certified guidelines) |
Note: The LINK US-5110SLZ-1 is a 1-meter CAT 6 UTP ultra-slim patch cord featuring a safe LSZH white jacket and high-flexibility 28 AWG conductors. Engineered specifically for high-density data center racks, it maximizes airflow and cabinet organization while delivering reliable 10 Gbps Ethernet performance.
Important: Utilizing an advanced slim-profile structure and low-smoke zero-halogen materials, the LINK US-5110SLZ-1 patch cord is the premier choice for network professionals optimizing space, airflow, and fire safety compliance in high-density switch configurations.
