Specifications Ruijie RG-AP810-L
| Features | Description |
|---|---|
| Product Type | Wi-Fi 6 Dual-Radio Indoor Access Point |
| Wireless Standard | IEEE 802.11a/b/g/n/ac/ax |
| Wireless Speed | Up to 1.775 Gbps |
| 2.4 GHz Speed | Up to 574 Mbps |
| 5 GHz Speed | Up to 1.201 Gbps |
| MIMO | 2×2 MIMO on 2.4 GHz and 5 GHz |
| Radio | Dual-Radio |
| OFDMA | Supported |
| MU-MIMO | Supported |
| Antenna & Interface | Description |
|---|---|
| Antenna | Built-in Omnidirectional Antennas |
| Antenna Gain | 2.4 GHz: 2 dBi; 5 GHz: 4 dBi |
| Ethernet Port | 1 × 10/100/1000BASE-T |
| Console Port | 1 × RJ45 Console |
| PoE | IEEE 802.3af |
| DC Input | 48 V DC / 0.3 A |
| Bluetooth | Bluetooth 5.1 |
| Capacity & Management | Description |
|---|---|
| Maximum Associated Clients | 256 |
| Recommended Active Devices | 64 for HD Video / 120 for General Usage |
| Maximum BSSIDs | 32 (up to 16 per radio) |
| Wireless Roaming | Layer 2 and Layer 3 Roaming |
| WDS | Supported |
| Cloud Management | Ruijie Cloud |
| Management | Console / Telnet / SSH / SNMP / TFTP |
| Security | Description |
|---|---|
| Authentication | RADIUS / 802.1X / WPA / WPA2 / WPA3 / Web Authentication |
| Encryption | WEP / WPA-Personal / WPA-Enterprise / WPA2 / WPA3 |
| ACL | Supported |
| MAC Filtering | Allowlist / Static Blocklist / Dynamic Blocklist |
| General | Description |
|---|---|
| Mounting | Wall / Ceiling Mount |
| Power Consumption | Maximum 12.95 W |
| Operating Temperature | -10°C to 50°C |
| Operating Humidity | 5%–95%, Non-Condensing |
| Dimension | 220 × 220 × 49 mm |
| Weight | Approx. 0.6 kg |
| MTBF | 200,000 Hours |
Note: The Ruijie RG-AP810-L is a Wi-Fi 6 dual-radio indoor access point delivering up to 1.775 Gbps combined wireless throughput. It features 2×2 MIMO on both 2.4 GHz and 5 GHz, OFDMA, MU-MIMO, built-in omnidirectional antennas, a Gigabit Ethernet uplink with PoE support, Bluetooth 5.1, WPA3 security, intelligent roaming, and Ruijie Cloud management.
