Specifications Ruijie RG-CS86-12XMG4VS-UP
| Features | Description |
|---|---|
| Product Type | 12-Port Cloud-Managed Multi-Gigabit PoE Switch |
| Service Ports | 12 x 100/1000/2.5G/5G/10GBASE-T RJ45 Ports |
| Uplink Ports | 4 x 10GE/25GE SFP28 Ports |
| PoE Standard | IEEE 802.3af/at/bt |
| PoE Ports | All 12 RJ45 Ports Support PoE/PoE+/PoE++ |
| Maximum PoE Output | Up to 90 W per Port |
| PoE Budget | Up to 370 W |
| Switching Capacity | 440 Gbps |
| Forwarding Rate | 327 Mpps |
| MAC Address Table | 32,768 Entries |
| ARP Table | 16,000 Entries |
| IPv4 Routing Table | 16,000 Routes |
| IPv6 Routing Table | 16,000 Routes |
| VSU | Supports up to 2 VSU Members |
| Management | Ruijie Cloud, Web Management, CLI, SNMP, and Console |
| NETWORK FEATURES | Description |
|---|---|
| VLAN | IEEE 802.1Q, Voice VLAN, Super VLAN, Private VLAN, MAC VLAN, Protocol VLAN, and IP-Subnet VLAN |
| VLAN Capacity | Up to 4,096 VLANs |
| Link Aggregation | IEEE 802.3ad LACP |
| Spanning Tree | STP, RSTP, and MSTP |
| Ring Protection | ERPS (G.8032) |
| Routing | Static Routing, RIP, RIPng, OSPFv2, OSPFv3, IS-ISv4, and IS-ISv6 |
| DHCP | DHCP Client, DHCP Relay, DHCP Server, and DHCP Snooping |
| IPv6 | DHCPv6, DHCPv6 Relay, DHCPv6 Snooping, ND, and ND Snooping |
| Jumbo Frame | Up to 9216 Bytes |
| LLDP | LLDP / LLDP-MED |
| SECURITY & RELIABILITY | Description |
|---|---|
| CPU Protection | CPP and NFPP |
| Boot Redundancy | 1+1 Boot Redundancy with Dual Flash Chips |
| Optical Port Protection | Independent Optical Port Fault Isolation |
| Power Supply | Built-in Fixed AC Power Supply |
| Rated Input Voltage | 100-240 V AC, 50/60 Hz |
| Maximum Input Voltage | 90-264 V AC, 47-63 Hz |
| Maximum Input Current | 6 A |
| Maximum Power Consumption | 460 W at Full PoE Load |
| Fan | 3 x Fixed Fan Modules |
| Cooling | Fan Cooling, Front-to-Rear and Left-to-Rear Airflow |
| GENERAL | Description |
|---|---|
| Dimensions | 442 mm x 220 mm x 43.6 mm |
| Rack Height | 1 RU |
| Weight | Approx. 6.11 kg |
| Operating Temperature | 0°C to 45°C |
| Storage Temperature | -40°C to 70°C |
| Operating Humidity | 10% to 90% RH, non-condensing |
| Operating Altitude | 0 to 5,000 m |
| MTBF | Approx. 194,297 Hours |
| Surge Protection | Service Port: 4 kV; Power Port: 6 kV Common Mode / 6 kV Differential Mode |
Note: The Ruijie RG-CS86-12XMG4VS-UP is a 12-port cloud-managed multi-Gigabit PoE switch featuring 12 x 10GBASE-T RJ45 ports with auto-negotiation from 100 Mbps to 10 Gbps and 4 x 25GE SFP28 uplink ports. It is designed for high-bandwidth enterprise campus networks and next-generation Wi-Fi deployments.
Important: All 12 RJ45 ports support IEEE 802.3af/at/bt PoE, with up to 90 W per port and a maximum PoE budget of 370 W. The switch provides 440 Gbps switching capacity, 327 Mpps forwarding performance, VSU virtualization, Ruijie Cloud management, and advanced Layer 2/Layer 3 networking features.
