Specifications Reyee RG-NIS3100-4GT2SFP-HP
| Features | Description |
|---|---|
| Product Type | Industrial Layer 2 Managed PoE+ Switch |
| Series | RG-NIS3100 Series Industrial Switch |
| Ethernet Ports | 4 × 10/100/1000BASE-T PoE+ |
| SFP Ports | 2 × 1000Mbps SFP |
| PoE Standard | IEEE 802.3af/at |
| PoE Power Budget | 120W |
| Maximum PoE Output per Port | 30W |
| Switching Capacity | 12Gbps |
| Forwarding Rate | 8.93Mpps |
| Management | Web / Ruijie Cloud / Reyee App |
| HARDWARE | |
|---|---|
| Downlink Ports | 4 × 10/100/1000Mbps RJ45 PoE+ |
| Uplink Ports | 2 × 1000Mbps SFP |
| PoE Ports | Ports 1–4 |
| PoE Standard | IEEE 802.3af/at |
| Maximum PoE Output per Port | 30W |
| Total PoE Power Budget | 120W |
| MAC Address Table | 8K |
| SDRAM | 256MB |
| Flash Memory | 16MB |
| Packet Buffer | 4.1Mbit |
| PERFORMANCE | |
|---|---|
| Switching Capacity | 12Gbps |
| Forwarding Rate | 8.93Mpps |
| Packet Buffer | 4.1Mbit |
| MAC Address Capacity | 8,000 |
| Maximum VLAN | 4,094 |
| Jumbo Frame | 9,216 bytes |
| NETWORK FEATURES | |
|---|---|
| VLAN | IEEE 802.1Q VLAN |
| Port-Based VLAN | Supported |
| Voice VLAN | Supported |
| Link Aggregation | Static LAG |
| STP | IEEE 802.1D STP |
| RSTP | IEEE 802.1w RSTP |
| ERPS | Supported |
| IGMP Snooping | IGMP v1/v2/v3 |
| LLDP | Supported |
| LLDP-MED | Supported |
| Port Mirroring | Many-to-One Mirroring |
| Flow Control | Supported |
| Cable Detection | Supported |
| Loop Prevention | Supported |
| Broadcast Storm Suppression | Supported |
| Unknown Unicast Storm Suppression | Supported |
| POE FEATURES | |
|---|---|
| PoE Standard | IEEE 802.3af / 802.3at |
| PoE Budget | Up to 120W |
| Maximum Power per Port | 30W |
| PoE Power Pins | 1–2 (+), 3–6 (-) |
| PoE Watchdog | Supported |
| PoE Device Detection | Automatic |
| PoE Usage Alarm | Supported |
| Remote Camera Reboot | Supported via PoE Watchdog |
| 250m Extend Mode | Supported |
| SECURITY | |
|---|---|
| ACL | IP Standard ACL / MAC-based Extended ACL / IP-based Extended ACL |
| Port Isolation | Supported |
| IP Source Guard | Supported |
| Anti-ARP Spoofing | Supported |
| DHCP Snooping | Supported |
| 802.1X | Supported |
| AAA | Supported |
| Broadcast Storm Control | Supported |
| MANAGEMENT | |
|---|---|
| Cloud Management | Ruijie Cloud |
| Mobile Management | Reyee App / SON |
| Web Management | Supported |
| SNMP | SNMP v1/v2c/v3 |
| HTTP / HTTPS | Supported |
| Network Diagnosis | Ping / Traceroute |
| DDM | Digital Diagnostics Monitoring |
| Camera Recognition | Supported |
| SON | Self-Organizing Network |
| INDUSTRIAL & ENVIRONMENTAL | |
|---|---|
| Industrial Grade | True Industrial-Grade Design |
| ESD Protection | 8kV |
| Service Port Surge Protection | ±6kV Common Mode |
| Power Connector Surge Protection | ±4kV Common Mode / ±2kV Differential Mode |
| Protection Rating | IP40 |
| Salt Spray Resistance | Supported |
| Cooling | Fanless Design |
| Operating Temperature | -40°C to +65°C in enclosed cabinet; up to +80°C with appropriate forced-air ventilation |
| Storage Temperature | -40°C to +85°C |
| Operating Humidity | 5%–95% RH, Non-Condensing |
| Operating Altitude | -500m to 5,000m |
| MTBF | 400,000 Hours |
| POWER & GENERAL | |
|---|---|
| Power Supply | Dual 12–56V DC Power Inputs |
| Input Voltage | 12–56V DC |
| Rated Current | 7A |
| Power Consumption Without PoE Load | 12W |
| Maximum Power Consumption | 132W with PoE load at 21–56V DC |
| Dimensions | 165 × 132 × 85mm |
| Installation | DIN-Rail / Wall Mounting |
| Design | Fanless Industrial Design |
| Shipping Weight | 1.86kg |
| Warranty | 5 Years |
Note: The Reyee RG-NIS3100-4GT2SFP-HP is an industrial-grade Layer 2 managed PoE+ switch designed for harsh environments such as factories, CCTV installations, outdoor cabinets and coastal areas. It features 4 × 10/100/1000BASE-T PoE+ ports and 2 × Gigabit SFP uplink ports, with a total PoE budget of up to 120W. It provides 12Gbps switching capacity and 8.93Mpps forwarding performance, and supports VLAN, STP/RSTP, ERPS, IGMP Snooping, Link Aggregation, ACL, DHCP Snooping, PoE Watchdog and 250m Extend Mode.
Important: The Reyee RG-NIS3100-4GT2SFP-HP is a True Industrial-Grade Layer 2 Managed PoE+ Switch featuring 4 × Gigabit PoE+ ports and 2 × Gigabit SFP uplink ports. It provides a 120W PoE power budget with up to 30W per port, supports IEEE 802.3af/at, VLAN, STP/RSTP, ERPS, IGMP Snooping, Link Aggregation, ACL, DHCP Snooping, PoE Watchdog and 250m Extend Mode. The switch uses dual 12–56V DC power inputs, has 8kV ESD protection, ±6kV common-mode service-port surge protection and a fanless industrial design. It can operate from -40°C to +65°C in an enclosed cabinet, with operation up to +80°C under specified forced-air conditions. The device has a 5-year warranty.
