Specifications Ruijie Reyee RG-RAP6262
| Features | Description |
|---|---|
| Product Type | Wi-Fi 6 AX3000 Outdoor Omni-directional Access Point |
| Wireless Standard | IEEE 802.11a/b/g/n/ac/ax |
| Maximum Wireless Rate | Up to 2.974 Gbps |
| 2.4 GHz | Up to 573 Mbps, 2 × 2 MU-MIMO |
| 5 GHz | Up to 2.401 Gbps, 2 × 2 MU-MIMO |
| Antenna | Built-in Omnidirectional Antennas |
| Network Ports | 1 × Gigabit Ethernet + 1 × 1G SFP |
| Power | 12 VDC / 2 A or PoE / PoE+ |
| Maximum Power Consumption | 24 W |
| Outdoor Protection | IP68 |
| Operating Temperature | -30°C to +65°C |
| WIRELESS | |
|---|---|
| Wireless Standard | IEEE 802.11a/b/g/n/ac/ax |
| Radio Design | Dual-Radio, 4 Spatial Streams |
| 2.4 GHz | 2 × 2 MU-MIMO, up to 573 Mbps |
| 5 GHz | 2 × 2 MU-MIMO, up to 2401 Mbps |
| Maximum Wireless Rate | 2974 Mbps |
| 6 GHz | Not Supported |
| OFDMA | Supported |
| 1024-QAM | Supported |
| Channel Width | Up to 160 MHz |
| ANTENNA | |
|---|---|
| Antenna Type | Built-in Omnidirectional Antenna |
| 2.4 GHz Antennas | 2 Built-in Omnidirectional Antennas |
| 5 GHz Antennas | 3 Built-in Omnidirectional Antennas |
| NETWORK | |
|---|---|
| Ethernet Port | 1 × 10/100/1000BASE-T |
| SFP Port | 1 × 1G SFP |
| IPv6 | Supported |
| Management | Ruijie Cloud / Reyee Cloud |
| Mesh | Reyee Mesh Supported |
| WIRELESS CAPACITY | |
|---|---|
| Maximum Associated Clients | 64 clients on 2.4 GHz |
| 5 GHz Clients | 512 clients |
| Total Clients | Up to 512 clients with 2.4 GHz and 5 GHz enabled |
| Maximum Managed Devices | Up to 300 devices |
| POWER | |
|---|---|
| Power Supply | 12 VDC / 2 A |
| PoE | PoE / PoE+ |
| Maximum Power Consumption | 24 W |
| ENVIRONMENT & GENERAL | |
|---|---|
| Protection | IP68 |
| Operating Temperature | -30°C to +65°C |
| Mounting | Wall / Pole |
| Dimensions | Ø230 × 195 mm |
| Weight | ≤ 1.4 kg |
Note: The Ruijie Reyee RG-RAP6262 is a Wi-Fi 6 AX3000 high-performance outdoor omnidirectional access point featuring dual-band 2.4 GHz and 5 GHz wireless connectivity, up to 2.974 Gbps wireless throughput, built-in omnidirectional antennas, 1 × Gigabit Ethernet port, 1 × 1G SFP port, Reyee Mesh support, PoE/PoE+ power, and IP68 protection. It is designed for outdoor deployments such as parking areas, warehouses, plazas, parks, stadiums, and other large open areas.
Important: The RG-RAP6262 is the AX3000 model with 1 × Gigabit Ethernet + 1 × 1G SFP. Do not confuse it with the RG-RAP6262(G), which is an AX1800 model with 2 × Gigabit Ethernet ports.
