Specifications Reyee RG-SPL2032-SC
| Features | Description |
|---|---|
| Product Type | Passive Optical Splitter |
| Series | e-Lighten Passive Optical Splitter |
| Optical Configuration | 2-In 32-Out Uniform Optical Splitter |
| Optical Split Ratio | 1:32 |
| Uplink Optical Ports | 2 × SC |
| Splitter Downlink Ports | 32 × SC |
| Operating Wavelength | 1260–1650nm |
| Power Requirement | None / Passive |
| OPTICAL SPECIFICATIONS | |
|---|---|
| Splitter Type | Uniform Optical Splitter |
| Optical Input Ports | 2 |
| Optical Output Ports | 32 |
| Split Ratio | 1:32 |
| Optical Connector | SC |
| Operating Wavelength | 1260–1650nm |
| Insertion Loss | ≤17.7dB |
| Port Insertion Loss Uniformity | ≤1.5dB |
| Return Loss | ≥50dB |
| Polarization-Dependent Loss | ≤0.3dB |
| Temperature-Dependent Loss | ≤0.3dB |
| Wavelength-Dependent Loss | 0.4dB at 1310nm ±40nm / 1550nm ±40nm |
| Maximum Input Power | 500mW |
| NETWORK APPLICATION | |
|---|---|
| Network Type | Passive All-Fiber LAN |
| Application | Reyee e-Lighten Optical Access Network |
| Topology | Point-to-Multipoint Optical Distribution |
| Fiber Connection | Direct Fiber Connection |
| Passive Aggregation | Supported |
| Plug and Play | Supported |
| Power Requirement | No Power Required |
| INSTALLATION | |
|---|---|
| Rack Mounting | Supported |
| Wall Mounting | Supported |
| Waterproof Enclosure | Compatible |
| Standalone Installation | Supported |
| Combined Installation | Supported |
| Mounting Type | Rack / Wall Mounting |
| MECHANICAL | |
|---|---|
| Enclosure Material | Durable Iron Casing |
| Dimensions | 220 × 130 × 42mm |
| Net Weight | 0.98kg |
| Design | Compact Metal Enclosure |
| ENVIRONMENT & RELIABILITY | |
|---|---|
| Operating Temperature | -40°C to +85°C |
| Power Consumption | 0W – Passive Device |
| Maximum Input Power | 500mW |
| Reliability | High Reliability |
| Enclosure | Iron Casing |
| GENERAL | |
|---|---|
| Product Type | 2-In 32-Out Passive Optical Splitter |
| Fiber Interface | SC |
| Number of Inputs | 2 |
| Number of Outputs | 32 |
| Split Ratio | 1:32 |
| Power Supply | Not Required |
| Dimensions | 220 × 130 × 42mm |
| Net Weight | 0.98kg |
Note: The Reyee RG-SPL2032-SC is a 2-In 32-Out Uniform Passive Optical Splitter designed for Reyee e-Lighten optical access networks. It features 2 optical input ports and 32 optical output ports with a 1:32 split ratio. The splitter supports an operating wavelength of 1260–1650nm, direct fiber connection and passive aggregation without requiring electrical power. It features a durable iron casing and supports rack-mounted or wall-mounted installation.
Important: The Reyee RG-SPL2032-SC is a Passive Optical Splitter featuring 2 × SC optical input ports and 32 × SC optical output ports with a 1:32 split ratio. It requires no power supply and supports 1260–1650nm operating wavelength, passive aggregation and direct fiber connection. The unit measures 220 × 130 × 42mm, weighs approximately 0.98kg and operates from -40°C to +85°C.
